Bearing with a stretching rod,stretching rod with right or left-hand female thread.
It is made up of a spherical plain radial bearing of type GE···E or GE···ES and a stretching rod with welding slope.There is a dowel pin at the end of the rod.
For left-hand thread,suffix “L” is added to bearing number and thread sign,e.g.SILR30ES M22*1.5L-6H.
For d≤40, The thread is without retaining screw.
